Radar Smart Lock Solution: Pre-Sensing Unlock with Microwave Radar

After work, carrying groceries in both hands, unable to find your keys, and your phone is about to die—this is an all-too-familiar moment of frustration for people living away from home. Smart locks were supposed to put an end to this. Yet in reality, many users find themselves standing at the door, staring at their phone screens waiting for a connection—longer than it used to take to pull out a key.

“Why am I waiting for it?” — this common complaint reflects a long-standing contradiction in the smart lock industry: locks are connected, but the experience still remains in the era of “manual interaction.”

Industry Pain Point: Why Smart Locks Aren’t Truly “Smart”

In the smart home ecosystem, the door lock is the closest touchpoint to users—and often the one with the largest experience gap.

Current mainstream Bluetooth smart lock solutions still operate on a fundamentally “passive waiting” logic. The lock has no awareness of when you are approaching; it only begins the connection process after you take out your phone and initiate it manually.

Establishing a Bluetooth connection involves multiple steps: device discovery, pairing, and authentication. Under ideal conditions, this takes 2–3 seconds. However, with signal interference or mobile power-saving mechanisms, the wait can extend beyond 5 seconds. For users carrying items in both hands, these few seconds become a tangible barrier.

Power consumption is another challenge. To remain connectable at all times, the Bluetooth module must continuously broadcast and scan, leading to high energy usage. As a result, battery replacement cycles are significantly shortened, placing ongoing pressure on both user experience and after-sales service.

A deeper issue lies in security. Bluetooth signals lack spatial awareness—they cannot distinguish whether the person approaching the door is the homeowner, a passerby, or even a stranger following closely behind. No matter how robust identity authentication is, without awareness of real-world spatial context, security inevitably has blind spots.

The Breakthrough: Let the Lock “See” You First

To solve these issues, the fundamental working logic of locks must change—from passive connection waiting to active environmental perception.

This is the core approach WayTronic brings to the smart lock market. By integrating its WT41 series microwave radar sensing modules into smart lock systems and combining them with Bluetooth HID solutions, WayTronic creates a “perception + connection” architecture:

• Radar answers: “Is this person actually intending to enter?”
• Bluetooth answers: “Is this person authorized to enter?”

Only when both questions are answered does unlocking become truly intelligent.

In real-world use, the improvement is immediately noticeable. When a user approaches within 3–5 meters, the radar module detects motion and wakes up the lock’s main controller and Bluetooth module from deep sleep. By the time the user reaches the door, the Bluetooth connection is already established and authentication is complete. The door unlocks instantly.

No need to take out your phone. No need to stare at a screen. No need to pause. Just walk in—exactly as it should be.

WT41 Series: Pushing Performance Under Extreme Constraints

Smart locks are extremely sensitive to power consumption. Typically powered by 4–8 dry batteries, they must last for months or even over a year. Any additional module must operate under strict power limits.

The WT41 series delivers:

• Average operating current: 19μA
• Standby current: as low as 4μA

This allows the radar module to run continuously with negligible power consumption. Meanwhile, thanks to radar-triggered activation, the Bluetooth module no longer needs to broadcast constantly. It activates only when a valid target is detected, reducing its active time by over 90% and significantly extending battery life.

In terms of sensing performance, there are no compromises:

• Detection range: 0.5m to 15m
• Detection angle: ±60°
• Distance accuracy: ±0.25m
• Response time: up to 250ms

By the time a user takes a step toward the door, the system has already completed wake-up and preparation—achieving true “instant unlock upon arrival.”

For engineers, the WT41 series offers standardized UART/IO interfaces, allowing direct integration with the main controller without requiring additional human detection algorithms. Compared to similar solutions, integration time can be reduced by up to 40%, significantly lowering development barriers.

Additionally, parameters such as detection range and sensitivity can be flexibly adjusted via PC tools, enabling customization for various scenarios—from small residential entryways to large corporate corridors.

Microwave radar can penetrate acrylic, glass, and thin non-metallic materials.

Spatial Security: Eliminating Tailgating Risks

Security remains the core concern of smart locks.

With radar sensing, smart locks gain an entirely new dimension of security. The system can not only verify “who you are” but also determine “where you are” and “what you are doing.”

Unlocking is triggered only when three conditions are met simultaneously:

• Spatial position
• Behavioral intent
• Identity authentication

This effectively filters out interference from nearby pedestrians and enables detection of suspicious behaviors such as loitering or tailgating.

Automatic locking also benefits from radar sensing. The system can accurately determine whether a person has completely left the detection range and trigger auto-lock accordingly.

This is fundamentally different from Bluetooth-based logic. A Bluetooth disconnection could result from a dead phone, signal loss, or moving further inside the house—not necessarily from actually leaving. Only spatial awareness enables a true closed-loop security system.

A Shift in Product Philosophy

From touch-based wake-up to radar pre-sensing, from identity authentication to spatial security, the introduction of WayTronic’s WT41 series microwave radar is not just about adding a sensor—it represents a fundamental shift in product logic.

Today, the smart lock industry is saturated with hardware competition. What truly differentiates products is the refinement of user experience and a deep understanding of real-world scenarios.

When a lock can sense your return and prepare itself before you even realize “I’m home,” only then does it truly deserve to be called “smart.”

This reflects WayTronic’s product philosophy:
Great technology should be invisible to the user—it simply works, quietly and reliably, exactly when needed.
